7300 Remote Particle Counter
Model 7300
0.3 – 25 µm @ 1.2 LPM with long-life internal pump & battery
The Particles Plus® 7300 Remote Particle Counter measures 0.3 to 25 μm with a flow rate of 1.2 LPM and is the most versatile remote particle counter available. The 7300 can be used as a stand-alone battery operated instrument or it can be easily integrated into a building automation and cleanroom management system via Ethernet, or (optional) Wireless 802.11 b/g, RS485 or RS232.
The 7300 reports and displays 6 user-selectable particle size channels, as well as temperature and relative humidity, flow and sensor status, date of last calibration, serial number, laser on-time and date of manufacture for easy maintenance and warranty management.
View data and generate ISO 14644-1, EU GMP Annex 1 or FS 209E reports on screen or via printer, USB key, real time through its versatile output options or export to Particles Plus® data-download software. Particles Plus® counters can be controlled and monitored remotely via web browser.
The 7300 particle counter stores up to 45,000 time stamped particle count and environmental data records which provides data redundancy on every instrument. The 7300 also has a mass concentration mode that approximates density in μg/m³.
All Particles Plus® counters meet ISO 21501-4 and JIS B9921. The 7300 ensures compliance with an on-board pulse height analyzer.
| Measures 0.3 μm to 25 μm |
| 1.2 LPM flow rate |
| Long-life laser diode technology |
| Measures up to 6 channels of simultaneous data |
| Approximates mass concentration in μg/m³ |
| Large easy-to-use icon driven color touch screen display |
| Temperature and relative humidity probe included |
| Stores up to 45,000 sample records, 1,000 sample locations and 50 recipes |
| Easy configuration and transferable from instrument to instrument |
| Connect using Ethernet, USB or (optional) Wireless 802.11 b/g, RS485 or RS232. |
| Static or dynamic IP address (DHCP) |
| Displays and externally prints reports for ISO 14644-1, EU GMP Annex 1 and FS 209E |
| Internal audible alarm |
| User-definable reports |
| User-selectable channel sizes |
| Complies with ISO 21501-4 and JIS B9921 standards |
| Easy to clean and wipe down with minimal particle traps |
| Seamless integration into a facility monitoring system |
| Light weight stainless steel enclosure |
|
2 year limited warranty. Extended warranties available. |
| Size Range | 0.3 to 25 μm |
| Size Channels | Factory calibrated at 0.5, 0.7, 1.0, 3.0, 5.0, 10.0 μm variable binning |
| Flow rates | 1.2 LPM |
| Concentration Limit | 27,000,000 particles/ft3 @ 10% coincidence (per ISO 21501-4), 50,000,000 particles/ft3 @ 10% coincidence (as tested and validated) |
| Battery Run Time | >8 hours |
| Light Source | Long life laser diode |
| Counting Efficiency | 50% @ 0.3 μm; 100% for particles >0.45 μm per JIS |
| Zero Count | <1 count / 5 minutes (<2 particles / ft³) (per ISO 21501-4 & JIS) |
| Count Modes | Automatic, manual, real-time meter, cumulative/differential, mass concentration, count or concentration |
| Count Alarms | 1 to 9,999,999 counts |
| Calibration | NIST traceable |
| Display | 4.3″ (10.9 cm) WQVGA (480×272) color touch screen |
| Printer (Optional) | External thermal printer available |
| Vacuum Source | Internal pump with automatic flow control |
| Filtered Exhaust | Internal HEPA filter |
| Number of Channels | 6 |
| Custom Size Channels | Calibration for custom size channels available |
| Audible Alarm | Adjustable built-in alarm |
| Battery | Removable Li-ion |
| Battery Recharge Time | <2 hours |
| Reports | ISO 14644-1, EU GMP Annex 1, FS 209E |
| Recipes | 50 user-configurable recipes |
| Communication Modes | Ethernet and USB |
| Optional Communication Modes | Wireless 802.11 b/g, RS485 or RS232 |
| Environmental Sensor | Includes temperature and relative humidity probe 32º to 122ºF (0º to 50ºC) ±1ºF (0.5ºC), 15-90% ±2% relative humidity |
| Alarm | Alarms on counts for all particle sizes, low battery, sensor failure, environmental sensors and flow |
| Standards | ISO 21501-4 and JIS B9921 |
| Calibration | Recommended minimum once per year |
| External Surface | Stainless steel |
| Dimensions (L x W x H) | 5.2” x 4.15” x 8.25” (13.3 cm x 10.5 cm x 21 cm) includes barb fittings |
| Weight | 4 lb (1.8 kg) |
| Accessories | Operating manual on USB flash drive, isokinetic probe, temperature relative humidity sensor, filter, battery, data download software, USB cable, power supply & cable |
| Optional Accessories | Printed manual, spare battery, external battery charger, external printer and isokinetic probes |
| Buffer Memory | 45,000 sample records (rotating buffer) including particle count data, environmental data, locations and times. Scrollable on screen or printout |
| Sample Locations | Up to 1,000 locations 20 characters long |
| Sample Time | 1 second to 99 hours |
| Power | 110 to 240 VAC 50/60 Hz universal in-line power supply |
| Operating Conditions | 41º to 104ºF (5º to 40ºC) / 20% to 95% non-condensing |
| Storage Conditions | 32º to 122ºF (0º to 50ºC) / Up to 98% non-condensing |
| Warranty |
2 year limited warranty. Extended warranties available. |
 |  |  |  |
7000 Series Carrying Case Part Number: AS-99015 | Wireless 802.11 b/g with Output Antenna Part Number: EE-80092 | Battery 55Wh Rechargeable & Removable Part Number: EE-80003A | External 55h Battery Charger (For EE-80003A) Part Number: AS-99005A |
 |  |  |  |
Temperature and Humidity Probe Part Number: EE-80014A | Filter 0.1 CFM (2.83 LPM) Part Number: AS-99002 | Filter Assembly 0.1 CFM (2.83 LPM) Part Number: AS-99002A | RS-485/232 Connector (5 POS) Part Number: EE-79015A |
 |  |  |  |
Isoprobe Threaded (Ni Plated Al) 0.1 CFM (2.83 LPM) Part Number: PS-12041 | Isoprobe Threaded (Stainless) 0.1 CFM (2.03 LPM) Part Number: PS-12070 | Isoprobe Barbed (Stainless) 0.1 CFM (2.83 LPM) Part Number: PS-12022 | Inlet Fitting Barbed 1/8 (Stainless) Part Number: PS-12005 |
 |  |  |  |
External Thermal Printer Includes 2 Rolls of Paper Part Number: AS-99011 | Thermal Printer Paper Single Roll Part Number: AS-99012 | USB Cable 6ft (1.8m) Part Number: AS-99022 | Power Supply 15V ~2A 100-240 VAC Part Number: EE-80127 |
 |  |  |  |
Power Supply Connector USA, Japan, Philippines, Taiwan Part Number: EE-80128 | Power Supply Connector Europe & Korea Part Number: EE-80129 | Power Supply Connector UK, Malaysia & Singapore Part Number. EE-80130 | Power Supply Connector China & Australia Part Number: EE-80131 |
 |  |  |  |
Tubing (per foot) 3/8" OD (1/4" ID) Part Number: AS-99019 | Tubing (per foot) 3/8" OD (1/4" ID) Bev-A-Line XX Part Number: AS-99037 | IMS Software & User Manual (USB Key) Part Number: MN-24003 | 7000 Series Validation Manual Part Number: MN-MN-24005 |
| |||
7000 Series User Manual (Printed) Part Number: MN-24003P |
